Basic Line Single
- Peltier cooling
Product description
The Basic Line Single is made to hold and transport cold food easily and safely. The box is designed with ScanBox ExP construction that combines optimized insulation performance with high operational reliability and environmentally conscious choices.
The box is equipped with Peltier cooling that provides effective cooling down to 3°C in 45 minutes. Digitally adjustable temperatures ensure excellent food quality control. The cooling module has a compact design and is easy to clean. The unit has capacity for 12 containers in the GN 1/1 standard.
ScanBox Basic Line is equipped with digital temperature control on the back of the device, excenter lock, solid door, 160 mm lockable wheels, removable U-guide rails with 80 mm spacing, black RAL 9005, 220-230V single phase.
Model and size
Equipments
Technical specification
Name | Value |
---|---|
Rack pitch | 80 mm |
No of trays | 12 |
Rack load max | 9 kg |
Inside dimensions | W:352mm x H:1047mm x D:600mm |
Outer dimensions | W:540mm x H:1384mm x D:810mm |
Weight | 64 kg |
Voltage | 220-240 V |
Power rating | 1.48 A |
Effect - cold | 200 W |
Volume | 221 l |
Documents
Your configuration
BASCP12Basic Line Single
Technical specification
Name | Value |
---|---|
Rack pitch | 80 mm |
No of trays | 12 |
Rack load max | 9 kg |
Inside dimensions | W:352mm x H:1047mm x D:600mm |
Outer dimensions | W:540mm x H:1384mm x D:810mm |
Weight | 64 kg |
Voltage | 220-240 V |
Power rating | 1.48 A |
Effect - cold | 200 W |
Volume | 221 l |
