Banquet Line Combo
- Compressor cooling
- Fan heating
Product description
The Banquet Line Combo is manufactured to hold and transport cold and hot food in two separate compartments with GN 2/1 capacity. The box is designed with ScanBox ExP construction that combines optimized insulation performance with high operational reliability and environmentally conscious choices.
The lower compartment of the box is equipped with compressor cooling that provides effective cooling down to 3°C. The upper compartment of the box has a fan heating system that provides fast and uniform heat distribution and can reach operating temperatures of up to 90°C. Adjustable temperature and ventilation ensure excellent food quality control. ScanBox Banquet Line Combo has capacity for 24 containers in the GN 1/1 standard.
Equipped with ScanBox Digital Control, excenter lock, solid doors, 160 mm lockable wheels, removable U-guide rails with 80 mm spacing, black RAL 9005, 220-230V single phase as standard. The equipment can be easily adapted as required through available extra options.
Model and size
Equipments
Technical specification
Name | Value |
---|---|
Rack pitch | 80 mm |
No of trays | 12 |
Rack load max | 18 kg |
Inside dimensions | W:557mm x H:573mm x D:723mm |
Outer dimensions | W:740mm x H:1597mm x D:990mm |
Weight | 108 kg |
Voltage | 220-240 V |
Power rating | 4.64 A |
Effect - cold | 135 W |
Effect - Hot | 830 W |
Temperature range | 3 - 90 °C |
Volume | 230 l |
