Bakery Line Single
- Compressor cooling
Product description
Bakery Line Single is manufactured for the distribution of cold bakery products. The box is made according to the standard dimensions of bakery trays. The box is designed with ScanBox ExP construction that combines optimized insulation performance with high operational reliability and environmentally conscious choices.
The box is equipped with compressor cooling that provides effective cooling down to 3°C in 30 minutes. Digitally adjustable temperatures ensure excellent food quality control. ScanBox Bakery Line Single has capacity for 12 baking trays according to the standard dimensions of 400x600 or 450x600.
Equipped with ScanBox Digital Control, excenter lock, solid door, 160 mm lockable wheels, removable ‘L’ shaped runners with 100 mm spacing, black RAL 9005, 220-230V single phase with Type F electrical plug. The equipment can be easily adapted as required through available extra options.
Equipments
Technical specification
Name | Value |
---|---|
Rack pitch | 100 mm |
No of trays | 12 |
Rack load max | 9 kg |
Inside dimensions | W:487mm x H:1287mm x D:681mm |
Outer dimensions | W:675mm x H:1677mm x D:950mm |
Weight | 94 kg |
Voltage | 220-240 V |
Power rating | 1.55 A |
Effect - cold | 180 W |
Volume | 427 l |
Documents
Your configuration
BBSCC40Bakery Line Single
Technical specification
Name | Value |
---|---|
Rack pitch | 100 mm |
No of trays | 12 |
Rack load max | 9 kg |
Inside dimensions | W:487mm x H:1287mm x D:681mm |
Outer dimensions | W:675mm x H:1677mm x D:950mm |
Weight | 94 kg |
Voltage | 220-240 V |
Power rating | 1.55 A |
Effect - cold | 180 W |
Volume | 427 l |
